Integrating HashiCorp Vault with Event-Driven Ansible in AAP 2.6

Introduction

Event-Driven Ansible in AAP 2.6 adds support for external secret management systems, with HashiCorp Vault being a key integration. This guide shows you how to configure Vault with EDA for secure, enterprise-grade event-driven automation.

See also: Event-Driven Ansible Enhancements in AAP 2.6 — What's New

Why External Secrets for EDA?

Storing secrets directly in rulebooks or EDA configurations creates risk:

• Secrets are visible in version control
• Rotation requires configuration changes
• Audit trails are incomplete
• Compliance requirements may be violated

Prerequisites

• AAP 2.6 installed and operational
• HashiCorp Vault server (v1.12+) accessible from EDA
• Vault admin access to create policies and secrets
• Basic familiarity with EDA rulebooks

Step 1: Configure Vault

Create a Secret Engine

# Enable a KV secrets engine for EDA
vault secrets enable -path=eda kv-v2

Store Secrets

# Store webhook tokens
vault kv put eda/webhook token=my-secure-webhook-token

# Store API keys
vault kv put eda/integrations \
  pagerduty_key=pd-api-key-12345 \
  slack_webhook=https://hooks.slack.com/services/xxx

Create a Policy

# eda-policy.hcl
path "eda/data/*" {
  capabilities = ["read", "list"]
}

vault policy write eda-reader eda-policy.hcl

See also: Enhanced Kafka Integration for Event-Driven Ansible in AAP 2.6

Step 2: Configure EDA Authentication

AppRole Authentication (Recommended)

# Enable AppRole
vault auth enable approle

# Create role for EDA
vault write auth/approle/role/eda \
  token_policies="eda-reader" \
  token_ttl=1h \
  token_max_ttl=4h

Step 3: Configure EDA Credentials

In the AAP 2.6 UI:

1. Navigate to Event-Driven Ansible → Credentials
2. Create a new credential of type HashiCorp Vault
3. Enter your Vault URL, authentication method, and credentials

Step 4: Use Vault Secrets in Rulebooks

---
- name: Webhook handler with Vault secrets
  hosts: all
  sources:
    - ansible.eda.webhook:
        host: 0.0.0.0
        port: 5000
        token: "{{ vault_lookup('eda/webhook', 'token') }}"

  rules:
    - name: Handle incoming webhook
      condition: event.payload.status == "critical"
      action:
        run_job_template:
          name: "Remediate Issue"
          organization: "IT Ops"

See also: hashicorp.vault Ansible Collection: Complete Guide for AAP 2.7

Best Practices

1. Use AppRole — More secure than token-based auth for automated systems
2. Short TTLs — Keep token lifetimes short and enable renewal
3. Separate paths — Use dedicated Vault paths for EDA vs other systems
4. Audit logging — Enable Vault audit logging to track secret access
5. Rotation — Implement regular secret rotation schedules

Conclusion

HashiCorp Vault integration brings enterprise-grade secret management to Event-Driven Ansible. This is a critical capability for organizations with strict security and compliance requirements.
