Ansible win_ping Module: Test Windows Host Connectivity (Examples)

How to test Windows host availability?

Today we're going to talk about the simplest way to test if a Windows-managed host is available to receive our commands. I'm Luca Berton and welcome to today's episode of Ansible Pilot.

See also: Ansible Ping Module: Test Host Connectivity & Availability (Guide)

Ansible module win_ping

Today we're talking about Ansible module win_ping. The full name is ansible.windows.win_ping, which means that is part of the collection of the "windows" modules of ansible. Previously was part of the built-in collection. It's a module pretty stable and out for years. It verifies the ability of Ansible to login to the managed host and that there is a shell, usually PowerShell, that is able to execute our code. So it's pretty different for the ping in the network context. It's the Windows corresponding to the Ansible ping module.

Main Parameters

• data _string_ - pong

See also: Add Windows Registry on Windows-like systems - Ansible module win_regedit

Main Return Values

• ping _string_ success pong

People usually don't specify any parameters or use the return value. The win_ping module usually delivers the pong text to the endpoint. It's possible to personalize the text using the "data" parameter. The return value is the "ping" string, that contains the same string of the data input parameter. If we keep the default value we are going to use "pong" as a parameter and as the return value.

## Playbook Are you ready to make your hands dirty? Let's jump in a quick live Playbook of a playbook about the win_ping module. • win_ping.yml

---
- name: win_ping module Playbook
  hosts: all
  become: false
  gather_facts: false
  tasks:
    - name: test connection
      ansible.windows.win_ping:

code with ❤️ in GitHub

Conclusion

Now you know better the Ansible module win_ping and you could use it successfully in your playbook.

See also: Ansible Change Windows User Password: win_user Module (Examples)

Testing Windows Connectivity

Basic win_ping test

ansible windows_hosts -m ansible.windows.win_ping -i inventory.yml

Expected output:

win-server1 | SUCCESS => {
    "changed": false,
    "ping": "pong"
}

win_ping in a playbook

---
- name: Test Windows connectivity
  hosts: windows
  tasks:
    - name: Ping Windows hosts
      ansible.windows.win_ping:
      register: ping_result
- name: Show result
      ansible.builtin.debug:
        var: ping_result

Windows Inventory Setup

# inventory.yml
all:
  children:
    windows:
      hosts:
        win-server1:
          ansible_host: 192.168.1.100
        win-server2:
          ansible_host: 192.168.1.101
      vars:
        ansible_user: Administrator
        ansible_password: "{{ vault_win_password }}"
        ansible_connection: winrm
        ansible_winrm_transport: ntlm
        ansible_winrm_server_cert_validation: ignore
        ansible_port: 5986  # HTTPS

Troubleshooting Connection Failures

Error: "winrm or requests is not installed"

pip install pywinrm

Error: "connection refused" or timeout

Enable WinRM on the Windows host (run as Administrator in PowerShell):

# Quick setup (enables WinRM with default settings)
winrm quickconfig -q
# Or use the Ansible-provided script
Invoke-WebRequest -Uri https://raw.githubusercontent.com/ansible/ansible-documentation/devel/examples/scripts/ConfigureRemotingForAnsible.ps1 -OutFile ConfigureRemotingForAnsible.ps1
.\ConfigureRemotingForAnsible.ps1

Error: "certificate verify failed"

# Option 1: Disable cert validation (testing only)
ansible_winrm_server_cert_validation: ignore
# Option 2: Use HTTP instead of HTTPS (insecure)
ansible_port: 5985
ansible_winrm_scheme: http

Error: "authentication failed"

Check credentials and WinRM auth settings:

# On Windows host — check allowed auth methods
winrm get winrm/config/service/auth
# Enable basic auth if needed
winrm set winrm/config/service/auth @{Basic="true"}

win_ping vs ping

| Module | Target | Protocol | Tests | |--------|--------|----------|-------| | ansible.windows.win_ping | Windows | WinRM/PSRP | WinRM + PowerShell | | ansible.builtin.ping | Linux/Unix | SSH | SSH + Python |

⚠️ Never use ping for Windows hosts — it will fail because it tries SSH + Python.

FAQ

Can I use SSH instead of WinRM?

Yes, if OpenSSH is installed on the Windows host (Windows 10+ / Server 2019+):

ansible_connection: ssh
ansible_shell_type: powershell

How do I test connectivity for all hosts at once?

# Test all hosts (Linux + Windows)
ansible all -m ping -i inventory.yml        # Linux
ansible all -m win_ping -i inventory.yml     # Windows
# Or group-specific
ansible windows -m win_ping -i inventory.yml
ansible linux -m ping -i inventory.yml

win_ping works but tasks fail — why?

win_ping only tests basic connectivity. Tasks can fail due to: • Insufficient permissions (need Administrator for many operations) • Missing Windows features or PowerShell modules • Execution policy restrictions
